| 配备参数 |
外观尺寸（长*宽*高）300*200*30mm |
Appearance size (length * width * height) 300*200*30mm |
| 输入电压:DC 15V/2.4A 36V/2.7A 24V/6.5A |
Input voltage: DC 15V/2.4A 36V/2.7A 24V/6.5A |
| 湿度：85%RH@40℃ |
Humidity: 85%RH@40 ℃ |
| 工作温度：-25-85℃ |
Operating temperature: -25-85℃ |
| 储存温度：-45-125℃ |
The storage temperature: -45-125 ℃ |
| 输入单元 |
输入点25点 |
Input 25 points |
| 指示灯：红色LED |
Indicator: red LED |
| 动作电压：DC24V ±10% |
Operating voltage: DC24V ± 10% |
| 输入电流：DC 10mA |
Input current: DC 10mA |
| 隔离性：光耦隔离5KV |
Isolation: optocoupler 5KV |
| 输出单元 |
输出点33点 DC28点 RELAY输出：5点 |
The output 33 DC28 RELAY output: 5 |
| 隔离性：光耦隔离5KV |
Isolation: optocoupler 5KV |
| DC最大负载3A(连续负载测试） |
DC maximum load 3A (continuous load test) |
| DC瞬间最大峰值电流10A |
DC transient peak current 10A |
| 指示灯：绿色LED |
Indicator: the green LED |
| RELAY最大负载5A |
The maximum load 5A RELAY |
| RELAY瞬间最大峰值电流：8A |
RELAY transient peak current: 8A |
| 温度控制单元 |
加热段数：7段 |
The heating section number: 7 |
| 油温：1段 |
Temperature: 1 |
| 控制模式：模糊式PID控制 |
Control mode: fuzzy PID control |
| 误差范围0.25%±1℃ |
The error range of 0.25% ± 1 ℃ |
| 感温范围K type 0-400℃ |
The temperature range of 0-400 ℃ K type |
| 警报：上限、下限、热电偶断线 |
Warning: the upper limit, lower limit, the thermocouple wire |
| 模拟量输入 |
位置尺输入：动模、射出、托模、压力感测 |
Position: feet input movable mould, injection mould, support, pressure sensing |
| 最大扩充：6点 射座、Spare |
Maximum extension: 6 point shooting base, Spare |
| 解析度：16bit(0-65535) |
Resolution: 16bit (0-65535) |
| 调整方式：软体线性调整 |
Adjustment methods: software linear adjustment |
| 电源供应：DC 10V/500mA |
Power supply: DC 10V/500mA |
| 模拟量输出 |
2点 |
The 2 point |
| 解析度：12bit(0-4095) |
Resolution: 12bit (0-4095) |
| 电压控制：DC 10V |
Voltage control: DC 10V |
| 电流控制：DC 1A |
Current control: DC 1A |
| 全刻度范围线性调整 |
Full scale range of linear adjustment |
| 软体校正斜率控制 |
Software calibration slope control |
| 软体校正256段变化，最快反应速度0.01S |
Software calibration 256 periods, the fast reaction rate of 0.01S |
