| 尺寸（长*宽*高）：116*98*30mm |
Appearance size : 116*98*30mm |
| 输入电压：DC 24V/0.5A |
Input voltage: DC 24V/0.5A |
| 湿度：85%RH@40℃ |
Humidity: 85%RH@40 ℃ |
| 工作温度：-25-85℃ |
Operating temperature: -25-85 ℃ |
| 储存温度：-45-125℃ |
The storage temperature: -45-125 ℃ |
| 输入:8点 K型热电偶 继电器隔离 |
Input: Relay isolation 8:00 K-type thermocouple |
| 输出:8点 DC24V/50mA 5KV光电隔离 |
Output: 5KV Optical Isolation 8:00 DC24V/50mA |
| 通讯:CAN2.0B 5KV光电隔离 |
Communication: 5KV Optical Isolation CAN2.0B |
| 温度检测精度:±0.1℃ |
Temperature detection accuracy: ± 0.1 ℃ |
| PID控制精度:±1℃ |
PID control accuracy: ± 1 ℃ |
| 控制:比例/PID/风冷 |
Control: Proportional / PID / air-cooled By increasing the P7T board extended temperature segments can be extended 40 |
| 利用增加P7T板扩展温度段数可扩展40段 |
Appearance size : 116*98*30mm |
